Key Specifications | |
|---|---|
Max. Combined Material Thickness | 2 mm [0.08”] [Mild Steel] |
Throat Depth | 38 mm [1.50”] |
Cycle Time | 1 second |
Weight | 5.6 kg [12.4 lb] |
Input Pressure | Up to 5.5 BAR [80 PSI] |
Tool Size | 3.8 to 4.6 |
- High Volume Manual Clinching
- Steel & Aluminum Sheet Metal Fabrication
- HVAC Industry
- Metal Structure Assembly
- Roofing
- Furniture
- Filter Assembly
- Prototype Assembly
- Roller Garage Door Assembly
- Solar Panel Frames & Support Structures
- Optimized for Economical Clinching of Smaller & Simple Joints
- Clinches with Round Clinch Tools
- Quick Change Shut Height Cartridges for Optimal Material Thickness
- Interchangeable Anvils for Wider Range of Part Cross Sections
- Dual Handles for Operator Comfort
- Operates From a Single Shop Air Line
- 32 kN Compressive Force [3.6 Ton]
- Custom Anvils Engineered to Your Requirements
- Hose Assembly
- 15 cc Booster
- Rotation Hanger for Ergonomic Positioning
- Balancer for Weightless Operation
- Tog-L-Loc® 3.8, 4.6
- V-Loc™ 3.8. 4.6 (restrictions apply, long lead time)
