Key Specifications | |
|---|---|
Maximum Combined Material Thickness | 5.0 mm [0.20”] [Mild Steel] |
Throat Depth | 460 mm [18”] |
Maximum Stroke | 76 mm [3”] |
Cycle Time | 2 seconds |
Weight | 329 kg [725 lb] [Bench Mount] |
Standard Input Pressure | 5.5 BAR [80 PSI] |
Tool Size | 3.0 to 6.4 |
- High Volume Manual Clinching
- Steel & Aluminum Sheet Metal Fabrication
- HVAC
- Metal Structure Assembly
- Office Furniture
- Filter Assembly
- Prototype Assembly
- For Applications Requiring Larger Clinch Joint
- Large Force-Frame for Improved Processing Clearance
- Foot Pedal Controls Package for Operator Part Handling Convenience
- Quick Change Tooling for Multiple Applications
- Tool Guard
- Operates From a Single Shop Air Line
- 88 kN Compressive Force [10 Ton]
- Bench Model
- Floor Stand
- Reverse Tooling (Special Order)
- Laser Pointer for Accurate Joint Placement
- Custom Force-Frames Engineered to Your Requirements
- Tog-L-Loc® 3.0, 3.8, 4.6, 5.5, 6.4
- V-Loc™ 3.8, 4.6, 5.5, 6.4
